Genset Model |
Silent Type |
CU450GFS |
|
|
Standby Power (KW/KVA) |
360/450 |
||
|
Prime Power(KW/kVA) |
320/400 |
||
|
CUMMINS Diesel Engine |
Model |
NTA855-G7 |
|
|
Type |
water-cooled, in line, 4-stroke, direct injection |
||
|
Rated Power(kW) |
343 |
||
|
Aspiration |
Turbocharged and air-air cooled |
||
|
No.of Cylinder |
6 |
||
|
Bore x Stroke(mm) |
|
140x152 |
|
|
Displacement |
14 |
||
|
Compression Ratio |
|
14:1 |
|
|
Electronic Governor Rate |
|
≦1% |
|
|
Exhaust Temperature(°C) |
|
489 |
|
|
Lub oil Capacity(L) |
|
38.6 |
|
|
Rated Fuel Consumption75% (L/h) |
|
64.7 |
|
|
Stamford technology Alternator |
Model |
HC434F |
|
|
Rated Power(kW/kVA) |
|
320/400 |
|
|
Voltage Regulation |
|
≦±1 |
|
|
Excitation Type |
|
Brushless |
|
|
Controller |
UK Deepsea brand |
HGM6120 |
|
|
Fuel tank |
sub-base |
8hrs working capacity |
|
|
ATS with cabinet size(L*W*H) /weight (KG) |
800*800*1600mm /270kg |
||
|
Overall Size(mm) |
Length |
4150 |
|
|
Width |
1300 |
||
|
Height |
2180 |
||
|
Gross Weight(kg) |
3840 |
||
|
With battery, battery charger,shock absorber , manual book etc. |
|||
