Genset Model |
Silent Type |
WC350GES |
||
|
Standby Power (KW/KVA) |
308/385 |
|||
|
Prime Power(KW/kVA) |
280/350 |
|||
|
WEICHAI Diesel Engine |
Model |
WP10D360E201 |
||
|
|
Type |
water-cooled, in line, 4-stroke, direct injection,Mechanical pump |
||
|
|
Rated Power(kW) |
326 |
||
|
|
Aspiration |
Turbocharged and aftercooled |
||
|
|
No.of Cylinder |
6 |
||
|
|
Bore x Stroke(mm) |
126x130 |
||
|
|
Displacement |
9.726 |
||
|
|
Compression Ratio |
17:1 |
||
|
|
Electronic Governor Rate |
≦1% |
||
|
|
Exhaust Temperature(°C) |
489 |
||
|
|
Lub oil Capacity(L) |
30 |
||
|
|
Rated Fuel Consumption75% (L/h) |
66.7 |
||
|
Stamford technology Alternator |
Model |
HC444D |
||
|
|
Standby Power(kW/kVA) |
280/350 |
||
|
|
Voltage Regulation |
≦±1 |
||
|
|
Excitation Type |
Brushless |
||
|
Controller |
Smartgen brand |
HGM6110 |
||
|
Fuel tank |
sub-base |
8hrs working capacity |
||
|
Overall Size(mm) |
Length |
3950 |
||
|
|
Width |
1350 |
||
|
|
Height |
2050 |
||
|
Gross Weight(kg) |
3680 |
|||
|
With battery, battery charger,shock absorber , manual book etc. |
||||
