Supply scope
| Genset Model | Silent type | P825GFS | |
| Standby Power(kW/kVA) | 660/825 | ||
| Prime power(KW/KVA) | 600/750 | ||
| Diesel Engine | Brand | PERKINS | |
| Model | 4006-23TAG2A | ||
| Type | water-cooled, 4-stroke,direct injection , | ||
| rated Power(kW) | 632 | ||
| Aspiration | Turbocharging and intercooling |
||
| No.of Cylinder | 6 | ||
| Bore x Stroke(mm) | 160×190 | ||
| Compression Ratio | 13.6:1 | ||
| Piston speed m/s | 9.25 | ||
| Electronic Governor Rate | ≦1% | ||
| Noise @7m | >85db | ||
| Exhaust Temperature(°C) | 550 | ||
| Lub oil Capacity(L) | 113.4 | ||
| Rated Fuel consumption (L/h) | 117 | ||
| Displacement（L） | 22.9 | ||
| Governing Type | Electrical | ||
| Alternator | Brand | Stamford tech | |
| Model | 634B | ||
| Rated Output(KW/KVA) | 600/750 | ||
| Power Efficiency | 85.00% | ||
| Voltage Regulation | ≦±1.0 | ||
| Excitation Type | Brushless | ||
| Insulation Class | H | ||
| Remote Controller | brand & model | UK deepsea DSE6120+DSE890 | |
| seperate ATS with cabinet 1250A | L*W*H=800*600*2200mm | ||
| battery battery charger etc | including Remote monitoring and control Fuel-water separator, | ||
| Overall Size(mm) | Length | 5700 | |
| Width | 2100 | ||
| Height | 2550 | ||
| Gross Weight(kg) | 8450 | ||
| 40HC Loading quantity(set) | 2 | ||
